Dimensions
4.34 Aisle width with 800 x 1200 mm pallet along forks Ast (mm) 2062
4.35 Turning radius Wa (mm) 1390
Performance data
5.1 Driving speed, full load/no load km/h 4.0/4.5
5.2 Lifting speed, with/without load [m/s] 0.017/0.024
5.3 Lowering speed, with/without load [m/s] 0.09/0.06
5.8 Maximum climbing ability, with/without load % 6/16
5.10 Service brake Electric
Driving
6.1 Traction motor rating S2 60 min kW 0.75
6.2 Lifting motor rating at S3 15% kW 0.5
6.3 Battery acc. to DIN 43531/ 35/ 36 A, B, C, no 230x260x85
6.4 Battery voltage, nominal capacity K5 V/Ah 24/20
6.5 Battery weight kg 5
6.6 Energy consumption acc. to VDI cycle [kW/h] n/a
Other
8.1 Drive control method DC
8.4 Noise level dB(A) <74
Eco-design requirements for
electric motors and variable
speed drives
All motors in this industrial truck are exempt
from Regulation (EU) 2019/1781 because
these motors do not meet the description giv-
en in Article 2 "Scope", Item (1) (a) and be-
cause of the provisions in Article 2 (2) (h) "Mo-
tors in cordless or battery-operated equip-
ment" and Article 2 (2) (o) "Motors designed
specifically for the traction of electric vehicles".
All variable speed drives in this industrial truck
are exempt from Regulation (EU) 2019/1781
because these variable speed drives do not
meet the description given in Article 2
"Scope", Item (1) (b).
6
Technical Data
Eco-design requirements for electric motors and variable speed drives
