Linear Series LS5050 - Unit Installation Procedures

Installation
9
3
/
4
”
9
1
/
4
”
3
5
/
8
”
6
1
/
2
”
Chassis Opening
Structural Stud
End Caps
Wall
Panel
Caution: Do not install radio without rear cover installed:
No user-serviceable parts inside. Rear cover provides
protection against potential fire hazard.
26
