LH800U-2D(L)/LH800U-2D(R) OWNER’S/OPERATOR’S MANUAL 14.0
7. CONTROL AND PARTS FUNCTIONS
7-5
CAUTION
Do not switch on 4WD if the rear wheels are spining. This may cause
severe machine damage. When switch on 4WD or Diff Lock, the button
will stay in 4WD or Diff Lock position, but 4WD or Diff Lock mechanics
maybe still disengaged. Always apply throttle gently and let the wheels
move slightly to allow the 4WD or Diff Lock mechanics finally engage.
The 4WD or Diff Lock indicator on the speedometer will come on when
engaged.
KEY SWITCH
1.Insert the key to the key switch and turn it “ON”
1 “PREHEAT” 2 “OFF”
3 “ON” 4 “START”
2.Check Easy Checker(TM) lamps:
When the key is turned “ON”, lamps(1)(3)should come on. If trouble
should occur at any location while the engine is running, the warning
lamp corresponding to that location comes on.
