LH800U-2D(L)/LH800U-2D(R) OWNER’S/OPERATOR’S MANUAL 14.0
7. CONTROL AND PARTS FUNCTIONS
7-10
PARKING BRAKE LEVER
The parking brake lever is located at the left side of the
driver’s seat. It will help hold the vehicle from moving
while parked. To set the parking brake, pull the lever up
completely. The parking indicator light will come on if the
main switch is on. To release the parking brake, pull up
on the lever, press the release button, and then push the
lever all the way down. Be sure to fully release the
parking brake before starting out. Failure to do so may
result in poor performance and premature wearing of the
parking brake and V-belt.
1. Release button
2. Parking brake lever
AUTOMATIC TRANSMISSION GEAR SELECTOR OPERATION
The transmission gear selector is located at the right side of
the steering wheel. The transmission selector lever has four
positions: high forward; reverse; neutral; and low forward
NOTE: To extend belt life, use low forward gear in heavy
pulling situations and in situations where you are operating
below 7mph(11km/h) for extended periods of time.
NOTE: To extend belt life, use low forward gear in heavy pulling
situations and in situations where you are operating below
7mph(11km/h) for extended periods of time.
CAUTION
To change gears, stop the vehicle and with the engine idling, move the
lever to the desired gear. Shifting gears with the engine speed above
idle or while the vehicle is moving could cause transmission damage.
Always place the transmission in gear with the parking brake locked
whenever the vehicle is left unattended.
Maintaining shift linkage adjustment is important to assure proper
transmission function. Should you experience any shifting problem see
your dealer.
