LH800U-2D(L)/LH800U-2D(R) OWNER’S/OPERATOR’S MANUAL 14.0
16. MAINTENANCE
16 - 8
WHEEL NUT TORQUE SPECIFICATIONS
Bolt Size Specification
Front M12X1.25 69Ft.Lbs 95N.m
Rear M12X1.25 69Ft.Lbs 95N.m
NOTE: All nuts that have a cotter pin installed must be serviced by
an authorized Dealer.
Front Wheel Hub Tightening
Front wheel bearing tightness and spindle nut retention are critical
component operations. Service work must be performed by an
authorized dealer.
Tapered nuts: install with tapered side against wheel
AXLE BOOTS
●Rear Prop Shaft Boots,
●Front Axle (CV Joints, 4x4 model) Boots,
Check the protective boots for holes or tears. If any damage is found,
have them replaced by an authorized dealer.
