8
Installation
Business Internet Video Camera with Audio
Chapter 4
Verify that the Camera’s LEDs are lit.
LED Table
LED Color Activity Action
Ready Amber
Off Camera is powered off
On Camera is powered on
Blink Camera is booting
Network Green
Off
Network connection not
detected
On
Network connection
detected
Blink Sending/receiving data
NOTE: Hardware Installation steps 6 and 7 are
only necessary if you are using the WVC2300
Wireless-G Business Internet Video Camera.
Connect the antennas to the antenna connectors on 6.
the Camera.
Place the antennas in an upright position.7.
Configuration
Insert the Setup CD into your CD-ROM drive. If the CD 1.
doesn’t run automatically, go to My Computer and
click on your CD-ROM drive.
The Setup screen will appear. Click the 2. Click Here to
Start button.
The license agreement screen will appear, click 3. Next if
you agree and wish to proceed.
The Wizard will now search for your camera.4.
Once found highlight the camera and click Next.
To Next Page
