Linksys LAPAC1750 User Manual

Portal Profiles
Captive Portal
Profile
Select a profile to configure.
Protocol
Select the protocol used to access the Portal
Authentication web server. It can be HTTP or HTTPS.
Authentication
Select an authentication method for clients.
Local - The access point uses a local database to
authenticated wireless clients.
Radius - The access point uses a database on a
remote RADIUS server to authenticate wireless
clients. The RADIUS server must support EAP-MD5.
Password Only - Wireless clients only need a
password. Username is unnecessary.
No Password - Wireless clients accept defined terms
to access the wireless network. Password and
username both are unnecessary.
Landing Page
Enable Landing Page to determine where
authenticated wireless clients will be directed after
logging in at Captive Portal. Choose
Original URL or
Promotion URL .
Redirect to Original
URL
If Landing Page is enabled, this setting redirects
authenticated wireless clients from the Captive
Portal login screen to the URL the user typed in.
Promotion URL
Enter a URL to which authenticated clients will be
redirected from the Captive Portal login page.
Landing Page must be enabled and Redirect to
Original URL must be disabled.
Session Timeout
Set the session time in minutes. The access point will
disconnect authenticated clients when the session
time expires. Session time can range from 0 to 1440
minutes. The default is 0 minutes, which means no
timeout.
Local Authentication
Group Name
Assigns an existing group to the profile. All users who
belong to the group are permitted to access the
network through this portal. The option 'Default'
means a group which includes all users.
64

Linksys LAPAC1750 Specifications

General

Modulation	-
Frequency band	2.412 - 2.462, 5.18 - 5.24, 5.745 - 5.825 GHz
Channels quantity	11 channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3at, IEEE 802.3u
Wi-Fi data rate (max)	500 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Quality of Service (QoS) support	Yes
Internal	No
Placement	Ceiling, Wall
Certification	FCC, CE, IC
Product color	White
Cable lock slot type	Kensington
Supported network protocols	IPv6
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Security algorithms	802.1x RADIUS, WDS, WEP, WPA, WPA2
Number of SSID supported	16
Antenna features	Integrated antenna
Input current	1.5 A
AC input voltage	12 V
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	243.08 mm
Width	236.98 mm
Height	43.69 mm
