Linksys LAPAC1750 User Manual

Radius Authentication
Primary Server
Enter the IP address of the RADIUS Server on your
network.
Primary Server Port
Enter the port number used for connections to the
RADIUS Server.
Primary Shared
Secret
Enter the key value to match the RADIUS Server.
Backup Server
The Backup Authentication Server will be used when
the Primary Authentication Server is not available.
Backup Server Port
Enter the port number used for connections to the
Backup RADIUS Server.
Backup Shared
Secret
Enter the key value to match the Backup RADIUS
Server.
Password Only Authentication
Password
The password for the profile. Wireless clients only
need one password to access the wireless network.
Local User
Go to Configuration > Captive Portal > Local User to configure user settings for Captive Portal.
Up to 128 users are supported.
65

Linksys LAPAC1750 Specifications

General

Modulation	-
Frequency band	2.412 - 2.462, 5.18 - 5.24, 5.745 - 5.825 GHz
Channels quantity	11 channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3at, IEEE 802.3u
Wi-Fi data rate (max)	500 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Quality of Service (QoS) support	Yes
Internal	No
Placement	Ceiling, Wall
Certification	FCC, CE, IC
Product color	White
Cable lock slot type	Kensington
Supported network protocols	IPv6
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Security algorithms	802.1x RADIUS, WDS, WEP, WPA, WPA2
Number of SSID supported	16
Antenna features	Integrated antenna
Input current	1.5 A
AC input voltage	12 V
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	243.08 mm
Width	236.98 mm
Height	43.69 mm
