Linksys LAPAC2600 User Manual

Basic Wireless Settings
Wireless
Radio
Select the wireless radio from the list.
Radio 1 is for 2.4 GHz, and Radio 2 is for 5 GHz.
Enable Radio
Enable or disable the wireless radio.
Wireless
Mode
Select the desired option for radio 1:
G only - allow connection by 802.11G wireless stations
only.
N only - allow connection by 802.11N wireless stations
only.
B/G-Mixed - allow connection by 802.11B and G wireless
stations only.
B/G/N-Mixed (Default) - allow connections by 802.11N,
802.11B and 802.11G wireless stations.
Select the desired option for radio 2:
N/A-Mixed - allow connection by 802.11A and N wireless
stations only.
N only - allow connection by 802.11N wireless stations
only.
AC only - allow connection by 802.11AC wireless stations
only.
A/N/AC-Mixed - allow connection by 802.11A, 802.11N
and 802.11AC wireless stations.
Wireless
Channel
Select wireless channel of the radio.
If Auto is selected, the access point will select the best
available channel when device boots up.
If you experience lost connections and/or slow data
transfers, manually change the channel until you find which
channel is best.
31

Linksys LAPAC2600 Specifications

General

2.4 GHz	Yes
Frequency band	2.412 - 2.462, 5.18 - 5.24, 5.745 - 5.825 GHz
Channels quantity	13 channels
Number of VLAN IDs	17
Fit AP mode features	Wireless distribution system (WDS)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.1x, IEEE 802.3at
Receiver sensitivity	802.11b 11Mbps: -85dBm 802.11a/g 54Mbps: -73dBm 802.11n HT20 MCS7: -67dBm 802.11n HT40 MCS7: -65dBm 802.11n HT40 MCS7: -65dBm
Virtual LAN features	SSID-based VLAN assignment
Wi-Fi data rate (max)	1733 Mbit/s
Ethernet LAN data rates	1000 Mbit/s
Maximum data transfer rate	2533 Mbit/s
Output current	2.5 A
Output voltage	12 V
Power consumption (max)	25 W
Internal	No
Placement	Ceiling, Wall
Certification	FCC: 47 CFR FCC Part 15, Subpart B, Class B; 47 CFR FCC Part 15, Subpart C; 47 CFR FCC Part 15, Subpart E CE: EN55022, Class B; EN61000-3-2; EN61000-3-3; 55024; EN 301 489-1 / EN 301 489-17, Class B; EN 300 328; EN 301 893; EN 62311; EN 50385
Product color	White
LED indicators	System
Cable lock slot type	Kensington
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
Antenna features	Integrated antenna
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Security algorithms	802.1x RADIUS, HTTPS, SNMP, WPA, WPA2
Number of SSID supported	16
Service Set Identifier (SSID) features	Hidden SSID
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	243 mm
Width	237 mm
Height	43.69 mm
Weight	848 g
