Page #81 background imageLoading...
Page #81 background image
Match IP DSCP
Matches packets based on IP DSCP value.
Select From List
Choose a DSCP value from the list.
default Match packets with default dscp (000000)
af11 Match packets with AF11 dscp (001010)
af12 Match packets with AF12 dscp (001100)
af13 Match packets with AF13 dscp (001110)
af21 Match packets with AF21 dscp (010010)
af22 Match packets with AF22 dscp (010100)
af23 Match packets with AF23 dscp (010110)
af31 Match packets with AF31 dscp (011010)
af32 Match packets with AF32 dscp (011100)
af33 Match packets with AF33 dscp (011110)
af41 Match packets with AF41 dscp (100010)
af42 Match packets with AF42 dscp (100100)
af43 Match packets with AF43 dscp (100110)
cs1 Match packets with CS1(precedence 1) dscp
(001000)
cs2 Match packets with CS2(precedence 2) dscp
(010000)
cs3 Match packets with CS3(precedence 3) dscp
(011000)
cs4 Match packets with CS4(precedence 4) dscp
(100000)
cs5 Match packets with CS5(precedence 5) dscp
(101000)
cs6 Match packets with CS6(precedence 6) dscp
(110000)
cs7 Match packets with CS7(precedence 7) dscp
(111000)
ef Match packets with EF dscp (101110)
Match to Value
A custom DSCP value from 0 to 63.
Match IP
Precedence
Matches packets based on their IP Precedence value
from 0 to 7. This is applicable only when the type of
ACLs is IPv4.
81

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Linksys LAPAC2600 and is the answer not in the manual?

Linksys LAPAC2600 Specifications

General IconGeneral
2.4 GHzYes
Frequency band2.412 - 2.462, 5.18 - 5.24, 5.745 - 5.825 GHz
Channels quantity13 channels
Number of VLAN IDs17
Fit AP mode featuresWireless distribution system (WDS)
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.1x, IEEE 802.3at
Receiver sensitivity802.11b 11Mbps: -85dBm 802.11a/g 54Mbps: -73dBm 802.11n HT20 MCS7: -67dBm 802.11n HT40 MCS7: -65dBm 802.11n HT40 MCS7: -65dBm
Virtual LAN featuresSSID-based VLAN assignment
Wi-Fi data rate (max)1733 Mbit/s
Ethernet LAN data rates1000 Mbit/s
Maximum data transfer rate2533 Mbit/s
Output current2.5 A
Output voltage12 V
Power consumption (max)25 W
InternalNo
PlacementCeiling, Wall
CertificationFCC: 47 CFR FCC Part 15, Subpart B, Class B; 47 CFR FCC Part 15, Subpart C; 47 CFR FCC Part 15, Subpart E CE: EN55022, Class B; EN61000-3-2; EN61000-3-3; 55024; EN 301 489-1 / EN 301 489-17, Class B; EN 300 328; EN 301 893; EN 62311; EN 50385
Product colorWhite
LED indicatorsSystem
Cable lock slot typeKensington
USB 2.0 ports quantity0
Ethernet LAN (RJ-45) ports2
Antenna featuresIntegrated antenna
Storage temperature (T-T)-20 - 70 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)10 - 85 %
Security algorithms802.1x RADIUS, HTTPS, SNMP, WPA, WPA2
Number of SSID supported16
Service Set Identifier (SSID) featuresHidden SSID
Cables includedLAN (RJ-45)
Weight and Dimensions IconWeight and Dimensions
Depth243 mm
Width237 mm
Height43.69 mm
Weight848 g
