Match IP TOS
Matches a type of service from the dropdown list.
This is applicable only when the type of ACLs is IPv4.
Normal Service 0000
Minimize Monetary Cost 0001
Maximize Reliability 0010
Maximize Throughput 0100
Minimize Delay - 1000
IPv6 Flow Label
A number that is unique to an IPv6 packet is used by
end stations to signify QoS handling in routers. The
range is 0 to 1048575.
ACL Association
Go to Configuration > ACL > ACL Association to associate defined ACL profiles with SSIDs.
82

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Linksys LAPAC2600 and is the answer not in the manual?

Linksys LAPAC2600 Specifications

General IconGeneral
2.4 GHzYes
Frequency band2.412 - 2.462, 5.18 - 5.24, 5.745 - 5.825 GHz
Channels quantity13 channels
Number of VLAN IDs17
Fit AP mode featuresWireless distribution system (WDS)
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.1x, IEEE 802.3at
Receiver sensitivity802.11b 11Mbps: -85dBm 802.11a/g 54Mbps: -73dBm 802.11n HT20 MCS7: -67dBm 802.11n HT40 MCS7: -65dBm 802.11n HT40 MCS7: -65dBm
Virtual LAN featuresSSID-based VLAN assignment
Wi-Fi data rate (max)1733 Mbit/s
Ethernet LAN data rates1000 Mbit/s
Maximum data transfer rate2533 Mbit/s
Output current2.5 A
Output voltage12 V
Power consumption (max)25 W
InternalNo
PlacementCeiling, Wall
CertificationFCC: 47 CFR FCC Part 15, Subpart B, Class B; 47 CFR FCC Part 15, Subpart C; 47 CFR FCC Part 15, Subpart E CE: EN55022, Class B; EN61000-3-2; EN61000-3-3; 55024; EN 301 489-1 / EN 301 489-17, Class B; EN 300 328; EN 301 893; EN 62311; EN 50385
Product colorWhite
LED indicatorsSystem
Cable lock slot typeKensington
USB 2.0 ports quantity0
Ethernet LAN (RJ-45) ports2
Antenna featuresIntegrated antenna
Storage temperature (T-T)-20 - 70 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)10 - 85 %
Security algorithms802.1x RADIUS, HTTPS, SNMP, WPA, WPA2
Number of SSID supported16
Service Set Identifier (SSID) featuresHidden SSID
Cables includedLAN (RJ-45)
Weight and Dimensions IconWeight and Dimensions
Depth243 mm
Width237 mm
Height43.69 mm
Weight848 g
