Internet Phone Adapter with 2 Ports for Voice-over-IP
8
Chapter 3: Connecting the Phone Adapter
Placement Options
Wall-Mount Option
The Phone Adapter has two wall-mount slots on its back panel. The distance between the two slots is 58 mm
(2.28 inches).
1 Determine where you want to mount the Phone Adapter.
2. Drill two holes into the wall. Make sure the holes are 58 mm (2.28 inches) apart.
3. Insert a screw into each hole, and leave 5 mm (0.2 inches) of its head exposed.
4. Place the Phone Adapter so that the wall-mount slots line up with the two screws.
5. Place the wall-mount slots over the screws and slide the Phone Adapter down until the screws fit snugly into
the wall-mount slots.
Congratulations! The installation of the Phone Adapter is complete.
Figure 3-6: Measurement between
Wall-Mount Slots
