Linksys PAP2T User Manual

Internet Phone Adapter with 2 Ports for Voice-over-IP
3
Chapter 2: Getting to Know the Phone Adapter
Back Panel Ports
Chapter 2: Getting to Know the Phone Adapter
Back Panel Ports
The Phone Adapter’s ports are located on the back panel.
PHONE 1 Port For your primary Internet phone line, the PHONE 1 port allows you to connect your
telephone to the Phone Adapter using an RJ-11 telephone cable (not included).
PHONE 2 Port If you add a second Internet phone line, then use the PHONE 2 port. It allows you to connect
a second telephone (or fax machine) to the Phone Adapter using an RJ-11 telephone cable
(not included).
ETHERNET Port The ETHERNET port allows you to connect the Phone Adapter to your router or gateway
using a Category 5 (or better) Ethernet network cable.
POWER Port The POWER port is where you will connect the included power adapter.
NOTE: The Phone ports do not carry any voltage.
Figure 2-1: Back Panel

Linksys PAP2T Specifications

General

Brand	Linksys
Model	PAP2T
Category	Adapter
Language	English
