Internet Phone Adapter with 2 Ports for Voice-over-IP
4
Chapter 2: Getting to Know the Phone Adapter
The Front Panel
The Front Panel
The Phone Adapter’s LEDs are located on the front panel.
PHONE 1 LED The green PHONE 1 LED remains solid when your telephone or fax machine has a
registered connection to an Internet phone service provider through the PHONE 1 port. (The
connection is registered if your Internet phone service account is active.) It flashes quickly
when the phone is in use and flashes slowly when you have a message waiting.
PHONE 2 LED The green PHONE 2 LED remains solid when your telephone or fax machine has a
registered connection to an Internet phone service provider through the PHONE 2 port. It
flashes quickly when the phone is in use and flashes slowly when you have a message
waiting.
ETHERNET LED The green ETHERNET LED remains solid when the Phone Adapter is connected to your
network through the Ethernet port and flashes when there is data being sent or received.
Power LED The Power LED remains solid green when the Phone Adapter is powered on and ready. It
flashes when the Phone Adapter is booting up, undergoing a self-test, or performing a
firmware upgrade. If the LED lights up red, the Phone Adapter has failed its self-test or is
malfunctioning. Refer to “Appendix A: Troubleshooting” for more information.
Figure 2-2: Front Panel
