51
Chapter 5: Using the Web-based Utility for Configuration
Statistics Tab - Port Utilization
WebView Switches
Statistics Tab - Port Utilization
The Port Utilization screen displays the amount of resources each interface is currently consuming. Ports in green
are functioning normally, while ports in red are currently transmitting an excessive amount of network traffic.
Refresh Rate. Indicates the amount of time that passes before the port utilization statistics are refreshed. The
possible field values are:
• No Refresh. Indicates that the statistics are not refreshed.
• 15 Sec. Indicates that the statistics are refreshed every 15 seconds.
• 30 Sec. Indicates that the statistics are refreshed every 30 seconds.
• 60 Sec. Indicates that the statistics are refreshed every 60 seconds.
Statistics Tab - 802.1x Statistics
The 802.1X Statistic screen contains information about EAP packets received on a specific port.
Port. Indicates the port, which is polled for statistics.
Refresh Rate. Indicates the amount of time that passes before the EAP statistics are refreshed. The possible field
values are:
• No Refresh. Indicates that the EAP statistics are not refreshed.
• 15 Sec. Indicates that the EAP statistics are refreshed every 15 seconds.
• 30 Sec. Indicates that the EAP statistics are refreshed every 30 seconds.
• 60 Sec. Indicates that the EAP statistics are refreshed every 60 seconds.
Name. Displays the measured 802.1x statistic.
Description. Describes the measured 802.1x statistic.
Packet. Displays the amount of packets measured for the particular 802.1x statistic.
Figure 5-22: Statistics - Port Utilization
Figure 5-23: Statistics - 802.1x Statistics
