Chapter 5: Using the Web-based Utility for Configuration
Statistics Tab - GVRP Statistics
WebView Switches
Statistics Tab - GVRP Statistics
The GVRP Statistics screen contains device statistics for GVRP.
The GVRP Statistics screen is divided into two areas, GVRP Statistics Table and GVRP Error Statistics Table. The
following fields are relevant for both tables:
Interface. Specifies the interface type for which the statistics are displayed.
• Port. Indicates port statistics are displayed.
• LAG. Indicates LAG statistics are displayed.
Refresh Rate. Indicates the amount of time that passes before the GVRP statistics are refreshed. The possible
field values are:
• No Refresh. Indicates that the GVRP statistics are not refreshed.
• 15 Sec. Indicates that the GVRP statistics are refreshed every 15 seconds.
• 30 Sec. Indicates that the GVRP statistics are refreshed every 30 seconds.
• 60 Sec. Indicates that the GVRP statistics are refreshed every 60 seconds.
The GVRP Statistics Table contains the following fields:
Join Empty. Displays the device GVRP Join Empty statistics.
Empty. Displays the device GVRP Empty statistics.
Leave Empty. Displays the device GVRP Leave Empty statistics.
Join In. Displays the device GVRP Join In statistics.
Leave In. Displays the device GVRP Leave in statistics.
Leave All. Displays the device GVRP Leave all statistics.
The GVRP Error Statistics Table contains the following fields:
Invalid Protocol ID. Displays the device GVRP Invalid Protocol ID statistics.
Invalid Attribute Type. Displays the device GVRP Invalid Attribute ID statistics.
Figure 5-24: Statistics - GVRP Statistics
