Linksys WIRELESS-G WRT54GS User Manual

12
Chapter 4: Connecting the Wireless-G Broadband Router
Hardware Installation for Connection of One Router to Another
Wireless-G Broadband Router with SpeedBooster
10. Connect the AC power adapter to the Broadband Router's Power port and the other end into an electrical
outlet. Only use the power adapter supplied with the Broadband Router. Use of a different adapter may result
in product damage.
Now that the hardware installation is complete, proceed to “Chapter 5: Configuring the Wireless-G
Broadband Router,” for directions on using the Router’s Web-Based Utility to configure the Router’s
settings for your network.
Figure 4-8: Connecting the Power
IMPORTANT: Make sure you use the power
adapter that is supplied with the Router. Use of a
different power adapter could damage the Router.

Linksys WIRELESS-G WRT54GS Specifications

General

Wireless Standard	802.11g
Frequency Band	2.4 GHz
Ethernet Ports	4x 10/100 Mbps LAN, 1x 10/100 Mbps WAN
Security Features	WEP, WPA, WPA2, SPI Firewall
Data Transfer Rate	54 Mbps
Buttons	Reset, SecureEasySetup
Operating Temperature	32 to 104°F (0 to 40°C)
Storage Temperature	-4 to 158°F (-20 to 70°C)
Operating Humidity	10% to 85% Non-condensing
Storage Humidity	5% to 90% Non-condensing
Antenna	2 x External
LEDs	Power, DMZ, WLAN, LAN (1-4)
Power	12V DC
