Linksys WIRELESS-G WRT54GS User Manual

41
Chapter 5: Configuring the Wireless-G Broadband Router
The Status Tab - Router
Wireless-G Broadband Router with SpeedBooster
The Status Tab - Router
The Router screen on the Status Tab displays the Router’s current status.
Firmware Version. This is the Router’s current firmware.
Current Time. This shows the time, as you set on the Setup Tab.
MAC Address. This is the Router’s MAC Address, as seen by your ISP.
Router Name. This is the specific name for the Router, which you set on the Setup Tab.
Host Name. If required by your ISP, this would have been entered on the Setup Tab.
Domain Name. If required by your ISP, this would have been entered on the Setup Tab.
Configuration Type. This section shows the current network information stored in the Router. The information
varies depending on the Internet connection type selected on the Setup tab.
Figure 5-46: Status Tab - Router

Linksys WIRELESS-G WRT54GS Specifications

General

Wireless Standard	802.11g
Frequency Band	2.4 GHz
Ethernet Ports	4x 10/100 Mbps LAN, 1x 10/100 Mbps WAN
Security Features	WEP, WPA, WPA2, SPI Firewall
Data Transfer Rate	54 Mbps
Buttons	Reset, SecureEasySetup
Operating Temperature	32 to 104°F (0 to 40°C)
Storage Temperature	-4 to 158°F (-20 to 70°C)
Operating Humidity	10% to 85% Non-condensing
Storage Humidity	5% to 90% Non-condensing
Antenna	2 x External
LEDs	Power, DMZ, WLAN, LAN (1-4)
Power	12V DC
