Linksys WIRELESS-G WRT54GS User Manual

66
Appendix E: Finding the MAC Address and IP Address for Your Ethernet Adapter
For the Router’s Web-based Utility
Wireless-G Broadband Router with SpeedBooster
3. Write down the Physical Address as shown on your computer screen; it is the MAC address for your Ethernet
adapter. This appears as a series of numbers and letters.
The MAC address/Physical Address is what you will use for MAC address cloning or MAC filtering.
Another screen will show the Ethernet adapter’s IP address. (Shown in the example as 192.168.1.100.) Your
computer may show something different.
For the Router’s Web-based Utility
For MAC filtering, enter the 12-digit MAC address in this format, XXXXXXXXXXXX, WITHOUT the hyphens.
For MAC address cloning, enter the 12-digit MAC address in the MAC Address fields provided, two digits per field.
Figure E-4: MAC Address Filter List
NOTE: The MAC address is also called the Physical Address.
Figure E-5: MAC Address Clone

Linksys WIRELESS-G WRT54GS Specifications

General

Wireless Standard	802.11g
Frequency Band	2.4 GHz
Ethernet Ports	4x 10/100 Mbps LAN, 1x 10/100 Mbps WAN
Security Features	WEP, WPA, WPA2, SPI Firewall
Data Transfer Rate	54 Mbps
Buttons	Reset, SecureEasySetup
Operating Temperature	32 to 104°F (0 to 40°C)
Storage Temperature	-4 to 158°F (-20 to 70°C)
Operating Humidity	10% to 85% Non-condensing
Storage Humidity	5% to 90% Non-condensing
Antenna	2 x External
LEDs	Power, DMZ, WLAN, LAN (1-4)
Power	12V DC
