Chapter 5: Configuring the Wireless-G Broadband Router
The Wireless Tab - Wireless Security
Wireless-G Broadband Router with SpeedBooster
WPA2 Personal. WPA2 gives you two encryption methods, TKIP and AES, with dynamic encryption keys. Select
the type of algorithm, AES, or TKIP + AES. Enter a WPA Shared Key of 8-63 characters. Then enter a Group Key
Renewal period, which instructs the Router how often it should change the encryption keys.
WPA2 Enterprise. This option features WPA2 used in coordination with a RADIUS server. (This should only be
used when a RADIUS server is connected to the Router.) First, select the type of WPA algorithm you want to use,
AES, or TKIP + AES. Enter the RADIUS server’s IP Address and port number, along with a key shared between the
Router and the server. Last, enter a Key Renewal Timeout, which instructs the Router how often it should change
the encryption keys.
Figure 5-21: Wireless Tab - Wireless Security (WPA2
Personal)
Figure 5-22: Wireless Tab - Wireless Security (WPA2
Enterprise)

Linksys WIRELESS-G WRT54GS Specifications

General

Wireless Standard	802.11g
Frequency Band	2.4 GHz
Ethernet Ports	4x 10/100 Mbps LAN, 1x 10/100 Mbps WAN
Security Features	WEP, WPA, WPA2, SPI Firewall
Data Transfer Rate	54 Mbps
Buttons	Reset, SecureEasySetup
Operating Temperature	32 to 104°F (0 to 40°C)
Storage Temperature	-4 to 158°F (-20 to 70°C)
Operating Humidity	10% to 85% Non-condensing
Storage Humidity	5% to 90% Non-condensing
Antenna	2 x External
LEDs	Power, DMZ, WLAN, LAN (1-4)
Power	12V DC
