Chapter 3: Getting to Know the Wireless-G Range Expander
The Recess for the Power Plate
Wireless-G Range Expander
The Recess for the Power Plate
The back of the Range Expander has a two-pronged recess where its power plates can be connected. Two power
plates come with the Range Expander, one with two prongs for direct connection to a power outlet, and another
with a cord to reach a power outlet.
Either of these power plate can be slid into the recess and is fully connected when the orange tab snaps into
place. To remove the power plate, slide the tab to the right and slide out the power plate. Always unplug the
Range Expander from the power outlet before removing the power plate.
Figure 3-2: Recess for the Power Plate
NOTE: Users in the United Kingdom or Asia-Pacific region that use the UK-style
power plugs will only have the power plate with a cord to reach a power outlet.
