Rev: 06.29.18
Page 6
CCD-0001535
Power Unit Components
1. Fittings - High Pressure O-Ring Face - Size 4
2. Hose - ¼" I.D. 3000PSI - W.P. Rated
NOTE: Fittings are labeled with port assignments found stamped into the manifold for easy identification.
Fig. 4
Fig. 5
Motor Solenoid
12V DC
Power
Ground
Power
12V DC Motor
Pressure
Switch
Valve and
Valve Coil
Quick
Disconnect for
Flush and Fill
Hydraulic
Manifold
Quick
Disconnect for
Flush and Fill
Fill Cup
Return
Fittings
Extend
Fittings
