Rev: 12.27.2017
Page 13
LCI Level-Up Motorized Leveling Winnebago Industries up to 9-2015 Owner's
Jack Retract Procedures
1. Energize the system by pushing ON/OFF button (Fig. 5K) on control panel. The LCD screen will display
READY Jacks: Down".
2. Push "DOWN" button (Fig. 5B) to display "Auto Retract All" on the screen.
3. Push "ENTER" (Fig. 5C) to begin.
NOTE: If the need to stop the jacks from retracting arises, turn the system off and back on again by pushing
the "ON/OFF" button (Fig. 5K) twice. The coach can then be manually leveled by following steps 1-9
in the MANUAL LEVELING PROCEDURE section above. Press "ENTER" to acknowledge.
4. The jacks will retract and shut off automatically; the display will read "READY - Jacks: Up". Push the "ON/
OFF" button (Fig. 5K) on the Control Panel to de-energize the system. After a brief visual inspection
around the coach to verify the jacks are fully retracted, you may proceed to travel.
5. To retract in the MANUAL mode, push the "RETRACT" button (Fig. 5D) until it lights. By pushing any of
the JACK buttons, the jacks will retract in pairs, i.e. "FRONT" button, both front jacks will retract, etc.
6. “AUTO RETRACT” can also be commenced by pushing and holding the "RETRACT" button (Fig. 5D) for 1
second.
NOTE: In cold weather operation, always check to make sure all jacks, slide rooms, and steps are fully
retracted before travel.
NEVER LIFT ALL THE WHEELS OFF THE GROUND TO LEVEL THE COACH!
Lifting all wheels off the ground may result in death or serious personal injury.
