4
2. Installation Overview
q Ensure that the truck electrical
system meets specifications and
can provide at least 5 Amps for
the LectroCount
3
with all truck
accessories operating.
q Electrically ground the truck
seats.
q Mount supervisory control
module and printer in cab.
q Install battery/accessory cables.
q Install odometer kit (optional).
q Remove any existing mechanical
registration equipment.
q Remove any existing manual
preset valve.
q Install an electronically controlled
security valve or solenoid kit.
q Mount RSCB / REC
q Install pulser assembly (optional)
q Install Electronic Temperature
Volume Compensation Kit
(optional).
q Route Meter Signal Cable to
truck cab.
3. Parts Requirements
3.1 LIQUID CONTROLS SUPPLIED COMPONENTS
q RSCB / REC
q Meter Signal Cable (pre-wired to RSCB)
q Battery/Accessory Cable
q Supervisory Control Module
q Lap Pad (driver key pad)
q Ticket Printer with cables
3.2 LIQUID CONTROLS SUPPLIED OPTIONS
q ETVC Kit
q Pulse Output Device (pulser)
q Odometer Pulser
q Dual Meter Switch Box
q RAM Interface Module
q Two Stage Valve or 3-Way Solenoid
3.3 INSTALLER SUPPLIED PARTS
q Protective Sheathing/Conduit for cables
q All Fittings
q Hardware for Truck Computer Mounting Brackets
