Gocator Line Profile Sensors: User Manual
Gocator Web Interface • 227
Parameter Description
Source The sensor, or combination of sensors, that provides data
for the tool's measurements. For more information, see
Source on page 183.
Stream The data that the tool will apply measurements to.
In Surface mode, this setting is only displayed when a
section is defined on the surface data.
For more information on sections, see Sections on page 174.
Region The region to which the tool's measurements will apply. For
more information, see Regions on page 184.
FittingRegions Determines which data Gocator uses to fit the line over the
profile.
When Fitting Regions is enabled, Gocator uses the data
indicated by one of the following options:
l All Data: All of the data in the profile is used to fit the
line.
l 1 Region:Data from a fitting region you define in the
data viewer is used to fit the line.
l 2 Regions:Data from two fitting regions you define is
used to fit the line.
When Fitting Regions is disabled, to fit the line, Gocator
uses the measurement region if Region is enabled, or the
entire profile if Region is disabled.
When Fitting Regions is enabled and 1 Region or 2 Regions
is selected, you can set the region (or regions) graphically in
the data viewer, or you can expand the feature using the
expand button ( ) and enter the values in the fields. For
more information on regions, see Regions on page 184.
Percent
(Percentile measurement only)
The specified percentage of points around the best-fitted
line.
Filters The filters that are applied to measurement values before
they are output. For more information, see Filters on page
192.
Decision The Max and Min settings define the range that determines
whether the measurement tool sends a pass or fail decision
to the output. For more information, see Decisions on page
191.
Parameters
Anchor Description
X or Z Lets you choose the X or Z measurement of another tool to
use as a positional anchor for this tool.
Anchoring
