Gocator Device Files • 386
Element Type Description
Y 64f Y value of region.
Width 64f Width value of region.
Length 64f Length value of region.
Element Type Description
X 64f X value of region.
Y 64f Y value of region.
Z 64f Z value of region.
Width 64f Width value of region.
Length 64f Length value of region.
Height 64f Height value of region.
ZAngle 64f ZAngle value of region.
GDKParameter Surface Region 3D Type
Element Type Description
32s Geometric feature Id for parameter.
GDKParameter Geometric Feature Type
ProfileArea
A ProfileArea element defines settings for a profile area tool and one or more of its measurements.
Element Type Description
Name String Tool name.
Features
Collection Collection of geometric feature outputs available in the tool.
See ProfileArea above.
Source 32s Profile source.
Anchor\X String (CSV) The X measurements (IDs) used for anchoring.
Anchor\X.options String (CSV) The X measurements (IDs) available for anchoring.
Anchor\Z String (CSV) The Z measurements (IDs) used for anchoring.
Anchor\Z.options String (CSV) The Z measurements (IDs) available for anchoring.
StreamOptions Collection
A collection of StreamOptions on page 382 elements.
Stream\Step
32s The stream source step. Possible values are:
1 – Video
2 – Range
3 – Surface
4 – Section
Stream\Id 32u The stream source ID.
Type Boolean
Area to measure:
ProfileArea Child Elements
