Gocator Line Profile Sensors: User Manual
Gocator Device Files • 387
Element Type Description
0 – Object (convex shape above the baseline)
1 – Clearance (concave shape below the baseline)
Type.used Boolean Whether or not field is used.
Baseline Boolean
Baseline type:
0 – X-axis
1 – Line
Baseline.used Boolean Whether or not field is used.
RegionEnabled Boolean If enabled, the defined region is used for measurements.
Otherwise, the full active area is used.
Region
ProfileRegion2d
Measurement region.
Line
ProfileLine
Line definition when Baseline is set to Line.
Measurements\Area Area tool
measurement
Area measurement.
Measurements\CentroidX Area tool
measurement
CentroidX measurement.
Measurements\CentroidZ Area tool
measurement
CentroidZ measurement.
Features\CenterPoint
GeometricFeature
CenterPoint PointFeature.
Element Type Description
@id 32s Measurement ID. Optional (measurement disabled if not
set).
Name String Measurement name.
Enabled Boolean
Measurement enable state:
0 – Disable
1 – Enable
HoldEnabled Boolean
Output hold enable state:
0 – Disable
1 – Enable
SmoothingEnabled Boolean
Smoothing enable state:
0 – Disable
1 – Enable
PreserveInvalidsEnabled Boolean Preserve invalid measurements enable state
0 – Disable
1 – Enable
SmoothingWindow 32u Smoothing window.
Scale 64f Output scaling factor.
Area Tool Measurement
