Gocator Line Profile Sensors: User Manual
Protocols • 450
Field Type Offset Description
addressVersion byte 51 IP address version (always 4).
address[4] byte 52 IP address.
reserved[12] byte 56 Reserved.
prefixLength 32u 68 Subnet prefix length (in number of bits).
gatewayVersion byte 72 Gateway address version (always 4).
gatewayAddress[4] byte 73 Gateway address.
reserved[12] byte 77 Reserved.
controlPort 16u 89 Control channel port.
upgradePort 16u 91 Upgrade channel port.
healthPort 16u 93 Health channel port.
dataPort 16u 95 Data channel port.
webPort 16u 97 Web server port.
propertyCount 8u 99 Number of sensor ID properties.
properties
[propertyCount]
Property
100 List of sensor ID properties.
Field Type Description
nameLength 8u Length of the name.
name[nameLength] char Name string.
valueLength 8u Length of the value.
value[valueLength] char Value string.
Property
Control Commands
A client sends control commands for most operations over the Control TCP channel (port 3190).
The Control channel and the Upgrade channel (port 3192) can be connected simultaneously. For more
information on Upgrade commands, see Upgrade Commands on page 486.
States
A Gocator system can be in one of three states: Conflict, Ready, or Running. The client sends the Start
and Stop control commands to change the system's current state to Running and Ready, respectively.
The sensor can also be configured to boot in either the Ready or Running state, by enabling or disabling
autostart, respectively, using the Set Auto Start Enabled command.
In the Ready state, a sensor can be configured. In the Running state, a sensor responds to input signals,
performs measurements, drives its outputs, and sends data messages to the client.
The state of the sensor can be retrieved using the Get States or Get System Info command.
The Conflict state indicates that a sensor has been configured with a Buddy sensor but the Buddy sensor
is not present on the network. The sensor will not accept some commands until the Set Buddy
command is used to remove the configured Buddy.
