LMI Technologies Gocator 2180 - Measurements, Features, and Settings

Gocator Line Profile Sensors: User Manual
Gocator Web Interface • 251
Measurement Panel
Measurements, Features, and Settings
Measurement Illustration
X
Determines the X position of the center of the countersunk hole.
Y
Determines the Y position of the center of the countersunk hole.
Z
Determines the Z position of the center of the countersunk hole.
Measurements
