Gocator Line Profile Sensors: User Manual
Specifications • 628
Function Pin
Input 1 1
Input 1 GND 2
Reserved 3
Reserved 4
Reserved 5
Reserved 6
Reserved 7
Reserved 8
Reserved 9
Reserved 10
Reserved 11
Reserved 12
Reserved 13
Reserved 14
Reserved 15
Reserved 16
Input (16 pin connector)
The Input connector does not need to be wired up for proper operation.
Function Pin
Encoder_A+ 1
Encoder_A- 2
Encoder_B+ 3
Encoder_B- 4
Encoder_Z+ 5
Encoder_Z- 6
GND 7
+5VDC 8
Encoder (8 pin connector)
Master 400/800 Electrical Specifications
Specification Value
Power Supply Voltage +48 VDC
Power Supply Current (Max.) 10 A
Electrical Specifications
