Gocator Line Profile Sensors: User Manual
Gocator Device Files • 390
Element Type Description
Anchor\X String (CSV) The X measurements (IDs) used for anchoring.
Anchor\X.options String (CSV) The X measurements (IDs) available for anchoring.
Anchor\Z String (CSV) The Z measurements (IDs) used for anchoring.
Anchor\Z.options String (CSV) The Z measurements (IDs) available for anchoring.
StreamOptions Collection
A collection of StreamOptions on page 382 elements.
Stream\Step
32s The stream source step. Possible values are:
1 – Video
2 – Range
3 – Surface
4 – Section
Stream\Id 32u The stream source ID.
RegionEnabled Boolean Whether or not to use region. If region is disabled, all
available data is used.
Region
ProfileRegion2d
Measurement region.
WindowSize 64f A percentage of the profile point heights when ordered
from lowest to highest in a histogram, starting from the
highest points, to include in the bridge value calculation.
WindowSkip
64f A percentage of the profile point heights when ordered
from lowest to highest in a histogram, starting from the
highest points, to exclude from the bridge value calculation.
Combines with WindowSize to determine what portion of
the profile points are used in the bridge value calculation.
MaxInvalid
64f
The maximum percentage of invalid points.
NormalizeEnabled
Boolean Whether tilt normalization is enabled.
MaxDifferential
64f
Maximum differential between the lowest and highest
profile points (mm).
MaxDifferential.min 64f Maximum differential limit min (mm).
MaxDifferential.max 64f Maximum differential limit max (mm).
Measurements\BridgeValue Bridge Value tool
measurement
Bridge Value measurement.
Measurements\Angle Bridge Value tool
measurement
Angle measurement.
Element Type Description
@id 32s Measurement ID. Optional (measurement disabled if not
set).
Name String Measurement name.
Enabled Boolean
Measurement enable state:
BridgeValue Tool Measurement
