START UP MANUAL 1
QUICK LOAD SERVO S2
E-3
TABLE OF CONTENTS
1. STARTING THE BAR FEED SYSTEM 3
1.1 Description 3
2. SETTINGS RELATED TO INSTALLATION 4
2.1 End of bar position 4-5
2.2 Top-cut position 6-7
3. SETTINGS RELATED TO BAR STOCK AND MACHINED PARTS 7
3.1 Example 1: Set-up for round bars 7-8
3.2 Example 2: Set-up for hexagonal bars 8
3.3 Example 3: Set-up for square bars 9
3.4 Example 4: Set-up for "other" bars 10
4. MECHANICAL SETTINGS AND OPTIONAL ACCESSORIES 11
4.1 Replacement of the feeding pusher 11-13
4.2 Calibration of the loading table 14
4.3 Slope of the magazine table 15
4.4 Loading fingers up 15-16
5. PUTTING THE LATHE INTO OPERATION 17
5.1 Spindle reduction tubes 17
5.2 Shaped bars (hex and square) 18
