START UP MANUAL 7
QUICK LOAD SERVO S2
Note :
For more
information
concerning
the
parameters,
see Chapter 7,
point 5.
Note :
If the previous
profile was
"Other", a text
indicating that
the loading
table needs to
be adjusted
manually will
be displayed.
See point 4.2.
3. SETTINGS RELATED TO BAR STOCK AND MACHINED PARTS
3.1 Example 1: Start-up for round bars
Specifications
Bar profile Round
Bar diameter 20.0 mm
Length of pieces to be machined 55.0 mm
Thickness of the cutoff tool 2.0 mm
a) Set-up of parameters :
Conditions: The loading table is in low position
2 bars of the new diameter are on the loading table
Bar feeder in STOP mode
Press the [MENU] key; the remote station displays the following text :
MAIN MENU
Press the numeric key [1] (Part Setup); the displays reads:
LOADING OF : 1. ROUND MATERIAL
2. HEXAGONAL
3. SQUARE
4. OTHERS
On the keypad, select [1] Round
Press the [ENTER]
key twice; the remote station displays the following text:
NEW BAR STOCK DIAMETER
On the keypad enter [200]
Press the [ENTER] key twice; the motor (M2) engages and sets the loading table and the
loading fingers of the bar magazine. The remote command displays the following text :
INPUT OVERALL PART LENGTH
On the keypad, enter [570], which represents the sum of the bar length and the thickness
of the cut-off tool.
Press the [ENTER] key twice to store the data. Press the [ESC] key to exit the set-up
functions.
b) Mechanical settings :
C Install the 12 mm diameter pusher; see point 4.1
C If the stock is tubing, install the special adapter; see point 4.1.2
C Check that the table and the loading fingers are in the "Round bars" position; see
points 4.3 and 4.4
