14 START UP MANUAL
QUICK LOAD SERVO III
Note :
For more
information
concerning
the
parameters,
see Chapter 7,
point 5.
3.4 Example 4 : Start-up for bars of special profile
Specifications
Bar profile Other than round, hexagonal or square
Bar diameter Cannot be defined (Special profile)
Length of pieces to be machined 23.0 mm
Thickness of the cutoff tool 2.0 mm
a) Set-up of parameters :
Conditions: The loading table is in low position
2 bars of the new diameter are on the loading table
Bar feeder in STOP mode
Press the [MENU] key; the remote command displays the following text :
Press the [ENTER] key; the remote command displays the following text :
On the keypad, select [4] Other
Press the [ENTER] key twice.
MAIN MENU
1: PART SETUP
2: APPLICATION SETUP
3: POSITION/TORQUE
4: MISCELLANEOUS
FUNCTIONS
5: SERVICE
NEW STOCK
DIAMETER
0.000 INCHES
CURRENT DIAMETER
[****] INCHES
EDIT NEW VALUE AND
PRESS F4 (ENTER)
