START UP MANUAL 15
QUICK LOAD SERVO III
Unlike other profiles, when "Other" is entered, no profile needs to be entered.
The remote command displays the following text :
On the keypad, enter [25],
which represents the sum of the bar length and the thickness of the cutoff tool.
Press the [ENTER] key twice to store the data. Press the [ESC] key to exit the set-up
functions.
A text is displayed, indicating that the loading table will have to be adjusted in manual
mode. Follow the instructions of point 4.2 to calibrate the loading table manually.
b) Mechanical settings :
C Install the correct pusher adapted to the profile of the stock; see point 4.1
C If the stock is tubing, install the special adapter; see point 4.1.2
C Check that the table and the loading fingers are in the "Profiled bars" position; see
points 4.3 and 4.4
C Refer to Set-up for profiled bars; see point 5.2.
ENTER OVERALL
PART LENGTH
[ 0.00] INCHES
(INCLUDING PART
LENGTH, CUT-OFF TOOL
WIDTH AND FACE-OFF
LENGTH)
CURRENT LENGTH
*.*** INCHES
