Lochinvar 100 Series Installation & Service Manual

11
3 Hydronic piping (continued)
DIR #2000577546
HOT WATER
SUPPLY
BOILER WATER
IN
TEMPERATURE
GAUGE
COLD WATER SUPPLY
BOILER WATER OUT
Figure 3-4 Water to Water Heat Exchanger Multiple Units
Please note that these illustrations are meant to show system piping concept only, the installer is responsible
for all equipment and detailing required by local codes.
NOTICE
Indirect Plate Water Heater Installation & Service Manual

Lochinvar 100 Series Specifications

General

Brand	Lochinvar
Model	100 Series
Category	Water Heater
Language	English
