Lochinvar CP-M Series User Manual

13
Item
Description
Item
Description
1
L/H side panel with insulation
28
Flow pipe – part 3
2
Front panel with insulation
29
Pressure sensor
3
Ignition cable
30
Pressure sensor gasket
4
Ignition electrode with gasket and screws
31
Pump gasket 1½"
5
Heat exchanger rear wall insulation
32
Flow pipe – part 2
6
Burner door gasket
33
Pump
7
Burner door insulation
34
Heat exchanger connection pipe retaining clip
8
Burner door
35
Heat exchanger connection pipe
9
Burner door retaining nut
36
Heat exchanger connection pipe O-ring
10
Burner
37
High limit thermostat
11
Burner / gas-air mixing pipe gasket
38
Flow / return temperature sensor
12
Gas-air mixing pipe retaining screws
39
Flue gas temperature sensor
13
Gas-air mixing pipe
40
Heat exchanger outlet / flue spigot gasket
14
Combustion fan / gas-air mixing pipe gasket
41
Automatic air vent
15
Combustion fan
42
Condensate drain hose – air supply duct
16
Gas-air mixing box
43
Wall bracket
17
N/A
44
Heat exchanger rear wall thermostat
18
Gas inlet / outlet manifold gasket
45
Air pressure switch
19
Gas valve
46
Condensate drain hose – heat exchanger
20
Gas valve connection O-ring
47
Air pressure switch hose
21
Replacement fuses
48
Condensate water trap
22
Boiler control PCB
49
R/H side panel with insulation
23
Display PCB
50
Condensate water trap drain hose
24
PC connection cover
51
N/A
25
Terminal strip cover
52
Cable gland
26
Heat exchanger
53
Rubber grommet
27
Return pipe – part 2
TABLE 2.3 REMOVABLE COMPONENTS – CP-M+120
