12.10.2 SETTING OUTSIDE TEMPERATURE COMPENSATION
The following figure describes how to program the outside temperature compensation curve.
FIGURE 12.15 SETTING OUTDOOR TEMPERATURE COMPENSATION
Operating screen:
H E A T I N G : S T A N D - B Y
> > > : 1 2 3 . 4
o
C ( 1 2 3 . 4
o
C )
Press [MENU]
Select "Outdoor" using [◄] & [►]
M a i n M e n u
O u t d o o r
Press [ENTER]
Confirmation screen:
A r e y o u s u r e
< C a n c e l ; > C o n f i r m
Press [◄] to cancel the changes made (unit will reset).
0 1 O u t s i d P r e s P5 AA
0
0 2 H C m i n O u T m p
P5 AC
- 1 5
o
C
0 3 H C m i n F l T m p P5 AD
8 5
o
C
0 4 H C m a x O u T m p P5 AE
2 0
o
C
0 5 H C m a x F l T m p P5 AF
2 0
o
C
0 6 H C m i n F l L i m
P5 AG
2 0
o
C
0 7 S u m S h D w n O u
P5 AH
3 0
o
C
0 8 H C m a x F l L i m P6 BA
8 5
o
C
0 9 H C n g h t s h f t P6 BB
- 1 0
o
C
0 A H C p a r a s h f t
P6 BC
5
o
C
0 B O u t S 1 2 k 1 0 k P5 AR
0
Press [►] to confirm the changes made. The time and day will start flashing for
a few seconds. After this, the display returns to its operating screen.
Press [◄] & [►] to browse through the screens that are shown below.
Press [▲] [▼] to change the flashing value in the selected screen.
Press [MENU] to exit. The unit will reset and go to the operating screen.
Press [ENTER] for confirmation screen after all changes are made.
