Lochinvar CP-M Series User Manual

16
Item
Description
Item
Description
1
L/H side panel with insulation
27
Flow pipe – part 3
2
Front panel with insulation
28
Pressure sensor gasket
3
Ignition cable
29
Pressure sensor
4
Ignition electrode with gasket and screws
30
Pump gasket 2"
5
Heat exchanger rear wall insulation
31
Flow pipe – part 2
6
Burner door gasket
32
Heat exchanger connection pipe retaining clip
7
Burner door insulation
33
Heat exchanger connection pipe
8
Burner door
34
Heat exchanger connection pipe O-ring
9
Burner door retaining nut
35
Pump
10
Burner
36
High limit thermostat
11
Burner / gas-air mixing pipe gasket
37
Flow / return temperature sensor
12
Gas-air mixing pipe retaining screws
38
Flue gas temperature sensor
13
Gas-air mixing pipe
39
Heat exchanger outlet / flue spigot gasket
14
Combustion fan / gas-air mixing pipe gasket
40
Automatic air vent
15
Combustion fan
41
Condensate drain hose – air supply duct
16
Gas-air mixing box
42
Wall bracket
17
Gas inlet manifold gasket
43
Heat exchanger rear wall thermostat
18
Gas valve
44
Air pressure switch
19
Gas valve outlet connection O-ring
45
Condensate drain hose – heat exchanger
20
Replacement fuses
46
Air pressure switch hose
21
Boiler control PCB
47
Condensate water trap
22
Display PCB
48
R/H side panel with insulation
23
PC connection cover
49
Condensate water trap drain hose
24
Terminal strip cover
50
N/A
25
Heat exchanger
51
Cable gland
26
Return pipe – part 2
52
Rubber grommet
TABLE 2.4 REMOVABLE COMPONENTS – CP-M+150 – CP-M+180
A replacement parts list is available to download from Lochinvar’s website; please visit www.lochinvar.ltd.uk
