Lochinvar CP-M Series User Manual

7
Item
Description
Item
Description
1
L/H side panel with insulation
29
Flow pipe
2
Front panel with insulation
30
Pump
3
Ignition cable
31
Pump gasket 1½"
4
Ignition electrode with gasket and screws
32
Return pipe – part 1
5
Heat exchanger rear wall insulation
33
Heat exchanger connection pipe gasket
6
Burner door gasket
34
Heat exchanger connection pipe
7
Burner door insulation
35
Heat exchanger connection pipe retaining clip
8
Burner door
36
Heat exchanger connection pipe O-ring
9
Burner door retaining nut
37
Flow / return temperature sensor
10
Burner
38
Return pipe – part 2
11
Burner / gas-air mixing pipe gasket
39
High limit thermostat
12
Gas-air mixing pipe retaining screws
40
Automatic air vent
13
Gas-air mixing pipe
41
Condensate drain hose – air supply duct
14
Combustion fan / gas-air mixing pipe gasket
42
Wall bracket
15
Combustion fan
43
Flue gas outlet pipe / flue spigot gasket
16
Gas-air mixing box
44
Flue gas outlet pipe
17
Gas valve outlet pipe
45
Heat exchanger / flue gas outlet pipe gasket
18
Gas valve inlet pipe
46
Flue gas temperature sensor
19
Gas inlet connector
47
Condensate drain hose – heat exchanger
20
Gas valve
48
Air pressure switch
21
Replacement fuses
49
Air pressure switch hose
22
Boiler control PCB
50
R/H side panel with insulation
23
Display PCB
51
Condensate water trap
24
PC connection cover
52
Condensate water trap drain hose
25
Terminal strip cover
53
N/A
26
Heat exchanger
54
Cable gland
27
Pressure sensor
55
Rubber grommet
28
Pressure sensor gasket
TABLE 2.1 REMOVABLE COMPONENTS – CP-M+60
