5.2 XS1 Connection Signal:
The system can be auto detecting when the footswitch(s) plug onto the system.
Only XS1 Channel A (Master) Footswitch plugged:
The footswitch can control both output of Channel A and Channel B and start at the same time.
Only XS1 Channel B Footswitch plugged:
The footswitch can only control the output of Channel B.
Both XS1 Channel A (Master) and XS2 Channel B Footswitch plugged:
The footswitch will control their own channel and can be started up at different times.
5.3 Start Up the System:
1. Turn the “POWER” on (the position marked “ ׀ ”) (12). The display (3) will turn on.
2. If necessary, open the valve or regulator that controls the air inlet to supply pneumatic pressure to
the system.
3. Turn the “AIR” on (the position ) (14).
Caution: When adjusting the pressure via “Pressure Regulator”, always adjust from Low-to-High.
For example, to adjust from 4 bar to 2 bar, decrease the pressure to 0~1 bar, then increase to 2 bar.
5.4 Run: Auto Mode
Engage the footswitch(s) to start the cycle. The dispensing will begin immediately and
continue until the system times out.
Notice:
Channel A and Channel B outputs are active only when the “OUTPUT” setting is set to “ON”. (Refer to
section 5.8)
5.5 Run: Manual Mode
Press the or to purge the adhesive manually without displaying or saving
parameters.
