Loctite 1390321 - Run: Continuous Mode; Setting Time (Auto) Mode; Setting Delay (Auto) Mode; Setting Output Mode

12
5.6 Run: Continuous Mode
Engage the footswitch(s) to start dispensing and hold until the dispensing cycle is
complete. When the footswitch is released, the dispensing will end immediately.
The display on the system will show the last dispensing time. If needed, press and
to store the dispensing time to “Run: Auto” Mode.
Notice:
Channel A and Channel B outputs are active only when the “OUTPUT” setting is set to “ON”. (Refer to
section 5.8)
5.7 Set: Time (Auto) Mode
Set the dispensing time for Channel A and Channel B in “Run: Auto” mode.
1. Press , the left most digit for Channel A will start to flash.
2. Press for numbering change on the flashing digit (0.01 – 99.99).
3. Press to move the flashing digit 1 digit to right.
4. Press again to switch from Channel A and Channel B.
5. After completed setting, press to save and exit.
5.8 Set: Delay (Auto) Mode
Set the delay time of Channel A and Channel B after engaged the footswitch in “Run:
Auto” mode.
1. Press , the left most digit for Channel A will start to flash.
2. Press for numbering change on the flashing digit (0.01 – 99.99).
3. Press to move the flashing digit 1 digit to right.
4. Press again to switch from Channel A and Channel B.
5. After completed setting, press
to save and exit.
5.9 Set: Output Mode
Enable or Disable the output for each channel.
1. Press , the setting for Channel A will start to flash.
2. Press
to switch between “ON” or “OFF”.
3. Press again to switch from Channel A and Channel B.
4. After completed setting, press to save and exit.
