1. Please Observe The Following
1.1 Emphasized Sections
Warning!
Refers to safety regulations and requires safety measures that protect the operator or other
persons from injury or danger to life.
Caution!
Emphasizes what must be done or avoided so that the unit or other property is not damaged.
Notice:
Gives recommendations for better handling of the unit during operation or adjustment as well as
for service activities.
Warning!
Never fill the product directly into the Product Reservoir! Insert only products packaged in
original Loctite® containers!
2. Description
2.1 Operation
The Loctite® Integrated Semi-Automatic Dispenser combines a dual channel dispense
controller and reservoir into a single system. The controller provides 2 independent digital
timing channels that provide control of 2 pneumatic outputs. These outputs can be used to
control dispense valves, advancing slides or any other pneumatic device. The controller can be
actuated either by a footswitch, finger switch or external signal. It is capable of operating in a
manual or time mode for dot or bead dispensing applications. The reservoir can accommodate
50ml, 250 ml, 500 gram, 1 liter, 2 kg and 200 gram adhesive packages which deliver adhesive
to dispensing valves. The system is also equipped with low level sensor which can notify the
operator that the adhesive package needs to be replaced.
- The Integrated Semi-Automatic Dispenser 1390322 is equipped with a precision pressure
regulator 0-1 bar (0-14 PSI).
- The Integrated Semi-Automatic Dispenser 1390321 is equipped with a pressure regulator 0-
7 bar (0-100 PSI).
With the Integrated Semi-Automatic Dispense System, anaerobic, UV Curing and
cyanoacrylate adhesive can be dispensed.
The capacity of the Integrated Semi Automatic Dispenser is:
- 500 gr. bottle for CA Product - 1 lb. bottle
- 250 ml bottle for Anaerobics - 1 Liter bottle
- Bottle with a Ø 124mm and - 2kg bottle
a height of 250mm
