3. Technical Data
3.1 Specifications
Attribute Value
Time Range 0 – 99.99 seconds
Air Input
*
Clean, dry air not to exceed 125 psig (8.5 bar),
and filtered with a maximum of 50 micron
Regulation Range of the Pressure
Regulator
1390322
0 – 2 bar
(0 – 28 PSI)
1390321
0 – 7 bar
(0 – 100 PSI)
Pressure Indication 0 – 1 bar
(0 – 14 PSI)
0 – 7 bar
(0 – 100 PSI)
Power Supply: 110 – 240 V / 50 – 60 Hz
Internal: 24 VDC
Power Connection: Includes plug ends for
North America/Japan, Continental Europe, UK,
Australia and China.
Width 7.29” (186mm)
Depth 14.26” (363mm)
Dimensions
Height 13.4” (341mm)
Weight 15.4lb (7 kg)
Operation Temperature + 10°C to + 40°C (+50°F to +104°F)
Storage Temperature - 10°C to + 60°C (+14°F to +140°F)
* If the required air quality is not achieved, install a Loctite
®
filter regulator. In the US
order a 5 m filter using part number 985397. In Europe or Asia, order a 10 m filter
using part number 97120.
