3 Technical Data
3.1 Energy Requirements
3.1.1 Electric’s
Power supply Power supply 90 – 260 V AC; 47 – 63 Hz
Power consumption Approx. 25 W
Power protection Glass tube, fine wire fuse, 2 A semi time-lag
Internal control voltage 24 V DC
3.1.2 Pneumatics
Pneumatic supply Min. 5 bar (70 PSI), max. 10 bar (145 PSI)
Quality
If the required quality is not
achieved, install a LOCTITE
filter regulator.
Filtered 10 µm, oil-free, non-condensing
Accessory Order No. 97120
Regulation range of the
pressure regulator
97007
0-8 bar
(0-115 PSI)
97008
0-4 bar
(0-60 PSI)
97009
0-4 bar
(0-60 PSI)
97010
0-1 bar
(0-15 PSI)
Pressure indication 0-10 bar
(0-145 PSI)
0-4 bar
(0-60 PSI)
0-4 bar
(0-60 PSI)
0-1 bar
(0-15 PSI)
3.2 Connections and Dimensions
Power connection Cold appliance coupling IEC 320 acc. to VDE 0625
Dimensions W x H x D: 350 x 335 x 230 mm (13.8 x 13.2 x 9.1 inch)
Pneumatic supply 97008 and 97009:
Internal Dia. 4 mm; external Dia. 6 mm +0.05, -0.10
External Dia. ¼ in. is not suitable!
97007 and 97010:
1/4” NPT fitting
