15
4 Installation
4.2 Space Requirements
4.3 Connecting the Unit
• Use only the cable and hose sets supplied.
• Connect power cord to power supply socket 6.
• Connect air pressure supply to pneumatic connection 8.
5 Dispensing
5.1 First Operation
• Check that the dispensing valve is connected correctly according to the operating manual.
• Switch the power switch 5 to position I (ON).
When you switch on the controller 97009 an empty signal with a peeping tone is indicated.
This will happen because there is no product bottle in the reservoir.
~230 mm
~9.1"
~335 mm
~13.2"
~350 mm
~13.8"
