8
1 Please observe the following
1.4 Field of Application (Intended Usage)
The Semi-automatic Dispense System is suitable for the exact application of LOCTITE products
at manual workstations such as in workshops, laboratories and industrial installations.
It is designed for a product application position.
– The Semi-automatic Dispense System 97010 is equipped with precision pressure regulator
0-1 bar (0-15 PSI).
– The Controller 97007 is equipped with a pressure regulator 0-8 bar (0-115 PSI).
– Both, 97008 and 97009 are equipped with a precision pressure regulator
0-4 bar (0-60 PSI).
– The Controller 97009 additionally has a low level sensor.
With the Semi-automatic Dispense System, anaerobic, UV curing and cyanoacrylate adhesives
can be dispensed.
The capacity of the integrated reservoir is:
– 500 gr. bottle for CA Products – 1 lb. bottle
– 250 ml bottle for Anaerobics – 1 Liter bottle
– Bottle with a ø 124 mm and – 2 kg bottle
a height of 250 mm
