4 Operation
4.1 Operation units / parts
(see fold-out sheet at front)
See figure 1
[1] Front bar
[2] Adjustable side bars (option)
[3] Tension bolt (back roller)
[4] Control panel
[5] Motor compartment for height adjustment and drive
[6] Magnetic contact for safety belt
[7] RS232 communication port on control panel
See figure 2
[1] On/ Off switch
[2] Connector for 230 V mains adapter
[3] Serial number tag
[4] Communication Interface Module (CIM)
[5] Protective earth connector
[6] Service connector
[7] Connector for the cable of the control unit
