Connect 32
User manual
122
Technical Data
Technical data
Changes of technical data and design of the equipment reserved.
Loewe device type:
Connect 32
Part number:
54446xxx
EU energy efficiency class:
see enclosed energy label or under www.loewe.tv/int/my-loewe
Screen diagonal:
81 cm / 32 inch
Power consumption On-Mode (max.)
(Audio output 1/8 of the maximum value):
73,0 W
Power consumption On-Mode (home)
(1
:
Annual energy consumption
(1
:
see enclosed energy label or under www.loewe.tv/int/my-loewe
Power consumption Standby Mode:
Power consumption when set is switched off:
0,40 W
0 W
Resolution:
Full HD 1920 x 1080 px
Display technology / Picture format: LCD with Edge-LED-Backlight / 16:9
Viewing angle (horizontal / vertical): 178° / 178°
Device dimensions without stand (W x H x D):
Device dimensions with stand
(2
(W x H x D):
72,9 x 47,7 x 5,3 cm
72,9 x 50,8 x 21,3 cm
Weight without stand (approximate):
Weight with stand
(2
(approximate):
9,7 kg
11,7 kg
Ambient temperature: 5° C – 35° C
Relative humidity (non-condensing): 20 – 80%
Air pressure: 800 – 1114 hPa (0 – 2000 m above sea level)
Chassis designation: SL 310F
Power supply: 220 V – 240 V/50–60 Hz
Tuner: terr./cable:
Satellite:
VHF/Hyperband/UHF
4 levels: 13/18V/22kHz / 16 levels: DiSEqC 1.0 / single-cable system: EN 50494
Range: terr./cable:
Satellite:
Terr./cable: 45 MHz up to 860 MHz
Satellite: 950 MHz up to 2150 MHz
Station storage locations incl. AV and radio: 6000
TV standards: analogue:
digital:
B/G, I, L, D/K, M, N
DVB-T/T2, DVB-C, DVB-S/S2 (UHD via DVB to max. 30 Hz)
Colour standards: SECAM, PAL, NTSC, NTSC-V, PAL-V (60 Hz)
Sound formats: analogue (FM):
analogue (NICAM):
digital (MPEG):
Mono, Stereo, Dual channel
Mono, Stereo, Dual channel
Mono, Stereo, Dual channel, PCM, Dolby Digital, Dolby Digital Plus, Dolby Digital Pulse, Dolby MS11
Audio output power (sine / music): 2 x 20W / 2 x 40W
Acoustic speaker concept: Speaker Box
Teletext: TOP / FLOF / HiText (Level 2.5)
Page memory: 2000
LAN: Standards supported: 10 Mbit/sec Ethernet (10Base-T) / 100 Mbit/sec Fast Ethernet (100Base-T)
WLAN: Standards supported:
Frequency range used:
Types of encoding that are supported:
IEEE 802.11a/b/g/n, 802.11ac
2400-2483,5 MHz and 5150-5725 MHz
WEP 64 and 128 Bit (ASCII and HEX), WPA PSK, WPA2 AES
Home networking standard: Universal Plug and Play Audio / Video (UPnP AV)
File formats supported
(3
: Pictures:
Audio:
Video:
JPEG, PNG
MP3, M4A (AAC LC), WMA (without lossless), FLAC, WAV (PCM), Ogg Vorbis
AVI (MPEG-1/2, XviD, AC3, MP3), WMV (WMV9, VC-1, WMA9, WMA Pro),
MP4 (XviD, H.264/MPEG-4 AVC, AAC LC), MOV (H.264/MPEG-4 AVC, AAC LC),
MKV (H.265/HEVC, H.264/MPEG-4 AVC, AC3), FLV (H.264/MPEG-4 AVC, H.263, MP3, AAC
LC),
MPG (MPEG-1, MPEG Audio), TS/PS (MPEG-2, H.264/MPEG-4 AVC, MPEG2 Audio, AC3)
,
VOB (MPEG-2, MPEG2 Audio, AC3)
H.264/MPEG-4 AVC upto Profil High (Level 4.2)
(1
The energy consumption per year is calculated on the basis of a daily four-hour operation of the TV set on 365 days. The actual energy consumption will depend on the
way the TV set is used. On-Mode (home) values less than 100 W must have decimal places (,0).
(2
Supplied mounting option: Table Stand Connect 32.
(3
For the playability of the individual formats no guarantee can be given.
