Loewe FL38 - CHASSIS LAYOUT; MAIN Unit (Side-A) Component Layout; MAIN Unit (Side-B) Component Layout

ITEMNMB DESCRIPTION
LIST-PART-NMB LAST-DATE
POSNR.
KURZTEXT
BESTELLNR.
ENTF-DAT.60415A70
Q302 TRANS 2SA1162Y-1 TRANSISTOR 344-90354935
Q303 TRANS DTC314TK-1 TRANSISTOR 344-90354936
Q304 TRANS DTC314TK-1 TRANSISTOR 344-90354936
Q305 TRANS DTC314TK-1 TRANSISTOR 344-90354936
Q308 TRANS DTC144EE-1 TRANSISTOR 344-90354937
Q4106 TRANS DTC144EE-1 TRANSISTOR 344-90354937
Q4107 TRANSISTOR UMG4/////-1 TRANSISTOR 344-90354970
Q4702 TRANS DIGITAL SOT323 NPN 50V 70MA 47K+ TRANSISTOR 344-27270
Q4709 TRANS DIGITAL SOT323 NPN 50V 70MA 47K+ TRANSISTOR 344-27270
Q4752 TRANS DIGITAL SOT323 NPN 50V 100MA 47K TRANSISTOR 344-28555 31.12.1999
Q4754 TRANS DIGITAL SOT323 NPN 50V 70MA 47K+ TRANSISTOR 344-27270
Q4772 TRANS DIGITAL SOT323 NPN 50V 70MA 47K+ TRANSISTOR 344-27270
Q4772 TRANS DIGITAL SOT323 NPN 50V 100MA 47K TRANSISTOR 344-28555
Q4774 TRANS DIGITAL SOT323 NPN 50V 70MA 47K+ TRANSISTOR 344-27270
Q4804 TRANS BC857W SOT323 TRANSISTOR 344-27468
Q4804 TRANS BC857BW SOT323 LV030 TRANSISTOR 344-28404
Q4832 TRANS BCR198W SOT323 PNP TRANSISTOR 344-27269
Q4833 TRANS BC847BW SOT323 TRANSISTOR 344-27272
Q701 TRANS 2SA1162Y-1 TRANSISTOR 344-90354935
Q702 TRANS 2SK2503-1 TRANSISTOR 344-90354938
Q703 TRANS 2SC2712Y-1 TRANSISTOR 344-90354933
Q707 TRANS DTC144EE-1 TRANSISTOR 344-90354937
Q708 TRANS FMMT718-1 TRANSISTOR 344-90354939
Q709 TRANS DTC144EE-1 TRANSISTOR 344-90354937
Q710 TRANS 2SA1162Y-1 TRANSISTOR 344-90354935
Q751 TRANS FZT1053A-1 TRANSISTOR 344-90354940
Q752 TRANS FZT1053A-1 TRANSISTOR 344-90354940
Q753 TRANS 2SA1162Y-1 TRANSISTOR 344-90354935
Q754 TRANS DTC114YE-1 TRANSISTOR 344-90354941
Q757 TRANS UPA606T-1 TRANSISTOR 344-90354942
10 FILT. OFW K 9463 M FILTER 290-25323
SPEZIALTEILE SPECIAL PARTS
20 DECKEL LID 501-87236011
21 DECKEL LID 501-87236011
21 KABELBAUM DISPLAY CONNECTING CABLE 171-90414947
2-12 SCHAUMGUMMI FRAME 549-90354989
2-2 RUECKWANDAUFKLEBER FRAME 549-90354979
25 TYPENSCHILD INDICATING UNIT 663-90414949
3-1 ABDECKUNG SELBSTKLEBEND SCHW. SCHLITZ COVER 568-90354986
3-2 SCHAUMGUMMI F. FUSSRING GEBOGEN 10 CM COVER 568-90354987
3-3 BODENPLATTE FUSSRING BOTTOM COVER 777-90354988
36 KABELBAUM 4-POL. CONNECTING CABLE 171-90354995
37 KABELBAUM 20-POL. CONNECTING CABLE 171-90354997
38 KABELBAUM 50-POL. CONNECTING CABLE 171-90354994
39 KABELBAUM 5-POL. CONNECTING CABLE 171-90354993
4 LAMPEN-SET INCANDESCENT LAMP 383-90354998
40 KABELBAUM 11-POL. CONNECTING CABLE 171-90354992
43 KABELBAUM 50-POL. CONNECTING CABLE 171-90414956
FB1202 SPULE CHOKE 296-90354964
FB1203 SPULE CHOKE 296-90354965
FB702 SPULE CHOKE 296-90354961
FB703 SPULE CHOKE 296-90354961
FB704 SPULE CHOKE 296-90354961
FB705 SPULE CHOKE 296-90354962
FB706 SPULE CHOKE 296-90354961
Dienstag, 19. März 2002
Seite 6
